Model Details
The rotary air/Hydraulic scissor lift table utilizes the convenience of factory air to power the lift table. Simply connect to an air supply through a filter, regulator, lubricator, and you will have a lift table suitable for a wide range of applications and operating environments. It features a pneumatic upper travel limit switch, safety toe guards, cylinder with internal safety velocity fuse, two button hand control, and life-time lubricated sleeve bearings.
Uniform Capacity (lb.): 3000 | Raised Height (in.): 43 | Minimum (psi): 80 |
Minimum (cfm): 80 | Minimum Supply (in.): 3/4 | Air Inlet Size (in.): 1/2 |
Platform Width/Length (in.): 30-3/8 x 60-3/8 |
Details For Model: AHLT-3060-3-43 |
||||||||||||||||||||||||
Steel Rotary Air Hydraulic Scissor Lift Table 30 In. x 60 In. 3,000 Lb. Capacity BlueThe rotary air/Hydraulic scissor lift table utilizes the convenience of factory air to power the lift table. Simply connect to an air supply through a filter, regulator, lubricator, and you will have a lift table suitable for a wide range of applications and operating environments. It features a pneumatic upper travel limit switch, safety toe guards, cylinder with internal safety velocity fuse, two button hand control, and life-time lubricated sleeve bearings.
|
||||||||||||||||||||||||
|
||||||||||||||||||||||||
