VHPS-2000-AA-17

Printer Friendly
Available
VHPS-2000-AA-17
VHPS-2000-AA-17 VHPS-2000-AA-17 VHPS-2000-AA-17 VHPS-2000-AA-17 VHPS-2000-AA-17

Steel Stacker Manual Pump 3 - 17 In. 1,500 - 2,000 Lb. Capacity Black / Yellow

Manual Hydraulic hand pump stackers are sturdy and compact to fit through standard height doors. Forks are raised by manual hydraulic hand pump operation and released by a lever situated on the handle. 1" lift per handle pump. Two rigid and two swivel wheels standard.

  • Manual lift design for precise positioning
  • Casters with brakes for safety
  • Adjustable forks for lifting an assortment of products
  • Large load capacity
Assembled Wt.(lbs.): 490 Assembled Size: 47.25"W x 64"L x 49"H

Total Ship Wt.(lbs.): 696 (only 1 package) Package 1 Size: 60"W x 64"D x 43"H Color: Black / Yellow

Uniform Capacity (lb.): 2,000 Service Range (in.): 3 to 17 Fork Length (in.): 42
Fork Width (in.): 4-1/2 Adjustable Straddle Leg Range (in.): 40-1/8 to 50 Adjustable Fork Spacing Range (in.): 7-7/8 to 26-3/4
Mast: Single Operation: Hand Pump Rear Caster Quantity/Diameter/Width (in.): (2) 7 x 2
Rear Caster Type: Poly on Steel Front Caster Quantity/Diameter/Width (in.): (2) 6 x 2 Front Caster Type: Poly on Steel
Pumps to Raise to Max Height (qty.): 21 Stroke per Pump (in.): 7/8 Time to Lower w/o Load (sec.): 5
Time to Lower w/ Load (sec.): 6 Steering Wheel Size (in.): 7 x 2

Quickship Item?

Quickship Item

Can It Ship UPS/FedEx?


LTL - Must Go Truck

Image Gallery

PDF Documents

1 Year Limited Warranty

Details For Model: VHPS-2000-AA-17
Available
VHPS-2000-AA-17

Steel Stacker Manual Pump 3 - 17 In. 1,500 - 2,000 Lb. Capacity Black / Yellow

Manual Hydraulic hand pump stackers are sturdy and compact to fit through standard height doors. Forks are raised by manual hydraulic hand pump operation and released by a lever situated on the handle. 1" lift per handle pump. Two rigid and two swivel wheels standard.

  • Manual lift design for precise positioning
  • Casters with brakes for safety
  • Adjustable forks for lifting an assortment of products
  • Large load capacity
Dimensions: 47.25"W x 64"L x 49"H Sell UOM: -- Color: Black / Yellow
Material: -- UPC: -- GTIN: --
Warranty: -- Shipping Weight: 696 Quickship Item? --
Can It Ship UPS? -- Option? -- Origin: --
Assembly: -- Packaging: -- Drawing Required? --
Uniform Capacity (lb.): 2,000 Service Range (in.): 3 to 17 Fork Length (in.): 42
Fork Width (in.): 4-1/2 Adjustable Straddle Leg Range (in.): 40-1/8 to 50 Adjustable Fork Spacing Range (in.): 7-7/8 to 26-3/4
Mast: Single Operation: Hand Pump Rear Caster Quantity/Diameter/Width (in.): (2) 7 x 2
Rear Caster Type: Poly on Steel Front Caster Quantity/Diameter/Width (in.): (2) 6 x 2 Front Caster Type: Poly on Steel
Pumps to Raise to Max Height (qty.): 21 Stroke per Pump (in.): 7/8 Time to Lower w/o Load (sec.): 5
Time to Lower w/ Load (sec.): 6 Steering Wheel Size (in.): 7 x 2
