Polyurethane Casters (Red Tread)Polyurethane on cast iron caster wheels are composed of a non-marking polyurethane tread that has been hand-painted and then cast upon an cast iron core. These wheels boast high weight capacities while maintaining superior, smooth rolling and floor protection. Reduced friction allows for a longer lifespan of these wheels. Polyurethane on cast iron caster wheels are most commonly found in both outdoor and indoor applications.
- Non-marking for good floor preservation
- Temperature rating of -45 degrees F to 180 degrees F
- Anti-corrosive & rust resistant Zinc Plated finish
- Roller bearing
High Quality Non-Marking Polyurethane-Elastomer
Polyurethane / Polyolefin Casters
Polyurethane (SI) Casters
All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.
The Search Box below is for Casters within the Model Chart on this page. Not an entire site search.
| Model | Image | PDFs | Caster Size |
Type | Capacity (lbs.) |
Overall Height |
Top Plate Size |
Net Wt. (lbs) |
|---|---|---|---|---|---|---|---|---|
| CST-PU-5X2-R |  | 1 Year Limited Warranty | 5 x 2 | RIGID | 661 | 9 | ||
| CST-PU-6X2-R |  | 1 Year Limited Warranty | 6 x 2 | RIGID | 772 | 7-1/2 | 4 x 4-1/2 | 11 |
| CST-PU-8X2-R |  | Limited Warranty | 8 x 2 | RIGID | 882 | 13 | ||
| CST-PU-5X2-S |  | 1 Year Limited Warranty | 5 x 2 | SWIVEL | 661 | 10 | ||
| CST-PU-6X2-S |  | Limited Warranty | 6 x 2 | SWIVEL | 772 | 7-1/2 | 4 x 4-1/2 | 12 |
| CST-PU-8X2-S |  | 1 Year Limited Warranty | 8 x 2 | SWIVEL | 882 | 14 | ||
| CST-PU-5X2-S-BR |  | Limited Warranty | 5 x 2 | SWIVEL W/SIDE BRAKE | 661 | 10 | ||
| CST-PU-8X2-S-BR |  | Limited Warranty | 8 x 2 | SWIVEL W/SIDE BRAKE | 882 | 15 |
KEY: = Click For Expanded Model Details -- = Approval Drawing -- = Testing Certificate -- Warranty
Polyurethane Casters (Red Tread) PDF's will open in a new window when clicked.
Manuals
No Owners Manuals For This Product
Survey Sheets
No Survey Sheets For This Product
Approval Drawings
No Approval Drawings For This Product
Testing Certificates
SDS Sheets
No SDS Sheets For This Product
Other PDF's
No "Other PDFs" For This Product...
