FEATURED Heavy-Duty Fiberglass Walk Ramps

model: FWR-3610-50


Heavy-Duty Fiberglass Walk Ramps
SERIES: FWR   6Products

Heavy Duty Fiberglass Walk Ramps for Truck and Equipment Loading

Heavy duty fiberglass walk ramps provide a strong, corrosion-resistant loading solution for moving equipment, carts, and materials into trucks, trailers, and elevated work areas. Designed for warehouses, maintenance crews, delivery operations, service departments, and industrial facilities, these ramps help create temporary access where a dock or permanent loading platform is not available.

Reinforced Fiberglass Construction

Reinforced fiberglass construction supports up to 3,000 lb. capacity while providing dependable performance in demanding loading and unloading applications. The durable ramp body is well suited for facilities that need a non-steel ramp option for repeated use around trucks and equipment.

Traction and Load Control

An abrasive walking surface helps provide traction in wet or dry conditions, giving users better footing during material transfer. A 1 inch high curb on each side helps guide carts and equipment while improving edge awareness during loading tasks.

Lengths, Widths, and Working Heights

This family includes 30 inch and 36 inch wide ramps in 10 foot, 12 foot, and 14 foot lengths. Maximum working heights range from 30 inches to 45 inches, allowing users to match ramp length and clearance to the truck bed, trailer, or loading application. These ramps are not for use with fork trucks or pallet trucks.

Heavy-Duty Fiberglass Walk Ramps

model: FWR-3610-50

Model # Description Attributes Net Wt.
(lbs)

All measurements are approximate. Slight variations, tolerances or changes may occur at any time. Weights shown are approximate shipping weights.

KEY: = Expand Model Details = Quickship item = Non-Returnable item = Approval Drawing Required = Non-Cancelable Item
= On Hold/Temporarily Unavailable = Approval Drawing = Testing Certificate = BABAA Compliant = 360 Image Warranty
= New Images Coming Soon! = Dimension Image = Works w/ Skid Only = Flatbed Truck Required

PDFs will open in a new window when clicked.

Owner's Manuals

0
No owner's manuals for this product family.

Survey Sheets

0
No survey sheets for this product family.

Approval Drawings

0
No approval drawings for this product family.

Testing Certificates

1

SDS Sheets

0
No SDS sheets for this product family.

Label Page PDFs

0
No label page PDFs for this product family.

Other PDFs

0
No other PDFs for this product family.




Heavy-Duty Fiberglass Walk Ramps




Heavy Duty Fiberglass Walk Ramps for Truck and Equipment Loading

Heavy duty fiberglass walk ramps provide a strong, corrosion-resistant loading solution for moving equipment, carts, and materials into trucks, trailers, and elevated work areas. Designed for warehouses, maintenance crews, delivery operations, service departments, and industrial facilities, these ramps help create temporary access where a dock or permanent loading platform is not available.

Reinforced Fiberglass Construction

Reinforced fiberglass construction supports up to 3,000 lb. capacity while providing dependable performance in demanding loading and unloading applications. The durable ramp body is well suited for facilities that need a non-steel ramp option for repeated use around trucks and equipment.

Traction and Load Control

An abrasive walking surface helps provide traction in wet or dry conditions, giving users better footing during material transfer. A 1 inch high curb on each side helps guide carts and equipment while improving edge awareness during loading tasks.

Lengths, Widths, and Working Heights

This family includes 30 inch and 36 inch wide ramps in 10 foot, 12 foot, and 14 foot lengths. Maximum working heights range from 30 inches to 45 inches, allowing users to match ramp length and clearance to the truck bed, trailer, or loading application. These ramps are not for use with fork trucks or pallet trucks.



Model # Description Attributes Net Wt.
(lbs)
FWR-3010-50 FWR-3010-50Heavy Duty Fiberglass Walk Ramp 120 In. x 30 In. 3000 Lb. CapacityUniform Capacity (lb.): 3000
Curb Height (in.): 1
225
FWR-3012-50 FWR-3012-50Heavy Duty Fiberglass Walk Ramp 144 In. x 30 In. 3000 Lb. CapacityUniform Capacity (lb.): 3000
Curb Height (in.): 1
260
FWR-3014-50 FWR-3014-50Heavy Duty Fiberglass Walk Ramp 168 In. x 30 In. 3000 Lb. CapacityUniform Capacity (lb.): 3000
Curb Height (in.): 1
260
FWR-3610-50 FWR-3610-50Heavy Duty Fiberglass Walk Ramp 120 In. x 36 In. 3000 Lb. CapacityUniform Capacity (lb.): 3000
Curb Height (in.): 1
260
FWR-3612-50 FWR-3612-50Heavy Duty Fiberglass Walk Ramp 144 In. x 36 In. 3000 Lb. CapacityUniform Capacity (lb.): 3000
Curb Height (in.): 1
314
FWR-3614-50 FWR-3614-50Heavy Duty Fiberglass Walk Ramp 168 In. x 36 In. 3000 Lb. CapacityUniform Capacity (lb.): 3000
Curb Height (in.): 1
300
